Connection components for earth conductors

Connection components

Rod to tape conductor connector, code: 6222040

Images
Additional Information
Certificates
Comply to 62561
Technical data
Material Copper (Cu)
Description Is consisted of two plates with dimensions 70x70 mm.
Bolts / nuts M8x30 mm, V2A stainless steel hexagon head bolts. M8 V2A stainless steel nuts.
Rod's / conductor's dimensions Ø20 mm rod (240 mm2 stranded conductor).
Tape's dimensionss 20 – 40 mm & up to 5 mm thickness.
Connection arrangements Cross (B1). Parallel (B2).
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Cu, Cu/eSn, Stainless Steel (SSt)
Can be connected buried in ground with Cu, Cu/eSn, Stainless Steel (SSt)
Can be connected in concrete with Cu, Cu/eSn, Stainless Steel (SSt), St/tZn
Tightening torque 13 Nm
Clamp, for connecting round rod or stranded conductor to tape conductor. Used in air termination system, down conductor system, earthing system.
H.S Code:
6222040-71
,
Product code:
6222040-71
,
Customs tariff No.:,
Gross weight:
430.00
gr,
PU:
Related products

Cu conductor connection clamp, code: 6221837

Images
Additional Information
Certificates
tested
Technical data
Material Copper (Cu)
Description Is consisted of two external plates with dimensions 50x50 mm and one intermediate plate.
Bolts / nuts M6x25 mm, V2A stainless steel carriage bolts. M6 V2A stainless steel nuts.
Conductor's dimensions 50–70 mm2 / 16–35 mm2
Connection arrangements Cross (B1). Parallel (B2).
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Cu, Cu/eSn, Stainless Steel (SSt), St/eCu
Can be connected buried in ground with Cu, Cu/eSn, Stainless Steel (SSt), St/eCu
Can be connected in concrete with Cu, Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn
Tightening torque 9 Nm
Clamp, for connecting solid round or stranded conductors. Used in air termination system, down conductor system, earthing system.
H.S Code:
6221837-71
,
Product code:
6221837-71
,
Customs tariff No.:,
Gross weight:
160.00
gr,
PU:
Related products

Round or stranded conductor connector, code: 6221818

Images
Additional Information
Certificates
tested
Technical data
Material Copper (Cu)
Description Is consisted of two external plates with dimensions 60x60 mm and one intermediate plate.
Bolts / nuts M8x30 mm, V2A stainless steel hexagon head bolts. M8 V2A stainless steel nuts.
Conductor's dimensions Ø8–10 mm (50–70 mm2)
Connection arrangements Cross (B1). Parallel (B2).
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Cu, Cu/eSn, Stainless Steel (SSt), St/eCu
Can be connected buried in ground with Cu, Cu/eSn, Stainless Steel (SSt), St/eCu
Can be connected in concrete with Cu, Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn
Tightening torque 13 Nm
Clamp, for connecting solid round or stranded conductors. Used in air termination system, down conductor system, earthing system.
H.S Code:
6221818-71
,
Product code:
6221818-71
,
Customs tariff No.:,
Gross weight:
374.00
gr,
PU:
Related products

St/tZn round or stranded conductor to rod connector, code: 6208116

Images
Additional Information
Certificates
Comply to 62561
Technical data
Material Hot dip galvanized steel (St/tZn)
Description Is consisted of two external plates with dimensions 60x60 mm and one intermediate plate.
Bolts / nuts M8x30 mm, St/tZn hexagon head bolts. M8 St/tZn nuts.
Conductor's dimensions Ø8–10 mm (50–70 mm2)
Rod's dimensions Ø16 mm
Connection arrangements Cross (B1). Parallel (B2).
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Al, Stainless Steel (SSt), St/tZn
Can be connected buried in ground with Stainless Steel (SSt), St/tZn
Can be connected in concrete with Cu, Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn
Tightening torque 13 Nm
Clamp, for connecting solid round or stranded conductor to air termination rod, earth lead-in rod, earth rod. Used in air termination system, down conductor system, earthing system....
H.S Code:
6208116-71
,
Product code:
6208116-71
,
Customs tariff No.:,
Gross weight:
358.00
gr,
PU:
Related products

St/tZn round or stranded conductor to rod connector, code: 6208020

Images
Additional Information
Certificates
ELEMKO_tested
Technical data
Material Hot dip galvanized steel (St/tZn)
Description Is consisted of two external plates with dimensions 90x30 mm and one intermediate plate.
Bolts / nuts M8x30 mm, St/tZn hexagon head bolts. M8 St/tZn nuts.
Conductor's dimensions Ø8–10 mm (50–70 mm2)
Rod's dimensions Ø20 mm
Connection arrangements Cross (B1)
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Al, Stainless Steel (SSt), St/tZn
Can be connected buried in ground with Stainless Steel (SSt), St/tZn
Can be connected in concrete with Cu, Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn
Tightening torque 13 Nm
Clamp, for connecting solid round or stranded conductor to round rod. Used in air termination system, down conductor system, earthing system.
H.S Code:
6208020-71
,
Product code:
6208020-71
,
Customs tariff No.:,
Gross weight:
264.00
gr,
PU:
Related products

St/tZn tape conductor connector, code: 6204060

Images
Additional Information
Certificates
tested
Technical data
Material Hot dip galvanized steel (St/tZn)
Description Is consisted of two external plates with dimensions 90x30 mm and one intermediate plate.
Bolts / nuts M8x30 mm, St/tZn hexagon head bolts. M8 St/tZn nuts.
Tape's dimensions Up to 60 mm width & up to 6 mm thickness.
Connection arrangements Cross (B1), up to 40 mm width. Parallel (B2), up to 60 mm width.
Installation Embedded in concrete.
Can be connected with Cu, Cu/eSn, Stainless Steel (SSt), St/tZn
Tightening torque 13 Nm
Clamp, for connecting tape conductors. Used in down conductor system, earthing system.
H.S Code:
6204060-71
,
Product code:
6204060-71
,
Customs tariff No.:,
Gross weight:
240.00
gr,
PU:
Related products

St/tZn rod to tape conductor connector with stainless steel screws, code: 6202041

Images
Additional Information
Certificates
Comply to 62561
Technical data
Material Hot dip galvanized steel (St/tZn)
Description Is consisted of two external plates with dimensions 60x60 mm and one intermediate plate.
Bolts / nuts M8x30 mm, St/tZn hexagon head bolts. M8 St/tZn nuts.
Rod's dimensions Ø20 mm
Tape's dimensions 20 – 40 mm & up to 5 mm thickness
Connection arrangements Cross (B1). Parallel (B2).
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Al, Stainless Steel (SSt), St/tZn.
Can be connected buried in ground with Stainless Steel (SSt), St/tZn.
Can be connected in concrete with Cu, Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn.
Tightening torque 13 Nm
Clamp, for connecting round rod to tape conductor. Used in air termination system, down conductor system, earthing system.
H.S Code:
6202041-71
,
Product code:
6202041-71
,
Customs tariff No.:,
Gross weight:
400.00
gr,
PU:
Related products

St/tZn rod to tape conductor connector, code: 6202040

Images
Additional Information
Certificates
Comply to 62561
Technical data
Material Hot dip galvanized steel (St/tZn)
Description Is consisted of two external plates with dimensions 60x60 mm and one intermediate plate.
Bolts / nuts M8x30 mm, St/tZn hexagon head bolts. M8 St/tZn nuts.
Rod's dimensions Ø20 mm
Tape's dimensions 20 – 40 mm & up to 5 mm thickness
Connection arrangements Cross (B1). Parallel (B2).
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Al, Stainless Steel (SSt), St/tZn.
Can be connected buried in ground with Stainless Steel (SSt), St/tZn.
Can be connected in concrete with Cu, Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn.
Tightening torque 13 Nm
Clamp, for connecting round rod to tape conductor. Used in air termination system, down conductor system, earthing system.
H.S Code:
6202040-71
,
Product code:
6202040-71
,
Customs tariff No.:,
Gross weight:
400.00
gr,
PU:
Related products

St/tZn round or stranded conductor connector with stainless steel screws, code: 6201819

Images
Additional Information
Certificates
tested
Technical data
Material Hot dip galvanized steel (St/tZn).
Description Is consisted of two external plates with dimensions 60x60 mm and one intermediate plate.
Bolts / nuts M8x30 mm, V2A stainless steel hexagon head bolts. M8 V2A stainless steel nuts.
Conductor's dimensions Ø8–10 mm (50–70 mm2).
Connection arrangements Cross (B1). Parallel (B2).
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Al, Stainless Steel (SSt), St/tZn.
Can be connected buried in ground with Stainless Steel (SSt), St/tZn.
Can be connected in concrete with Cu, Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn.
Tightening torque 13 Nm
Clamp, for connecting solid round or stranded conductors. Used in air termination system, down conductor system, earthing system.
H.S Code:
6201819-71
,
Product code:
6201819-71
,
Customs tariff No.:,
Gross weight:
348.00
gr,
PU:
Related products

St/tZn round or stranded conductor connector, code: 6201818

Images
Additional Information
Certificates
tested
Technical data
Material Hot dip galvanized steel (St/tZn).
Description Is consisted of two external plates with dimensions 60x60 mm and one intermediate plate.
Bolts / nuts M8x30 mm, St/tZn hexagon head bolts. M8 St/tZn nuts.
Conductor's dimensions Ø8–10 mm (50–70 mm2).
Connection arrangements Cross (B1). Parallel (B2).
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Al, Stainless Steel (SSt), St/tZn.
Can be connected buried in ground with Stainless Steel (SSt), St/tZn.
Can be connected in concrete with Cu, Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn.
Tightening torque 13 Nm
Clamp, for connecting solid round or stranded conductors. Used in air termination system, down conductor system, earthing system.
H.S Code:
6201818-71
,
Product code:
6201818-71
,
Customs tariff No.:,
Gross weight:
348.00
gr,
PU:
Related products
