Lightning Protection System (LPS) conductors

Αγωγοί ΣΑΠ

Αγωγοί για χρήση σε ΣΑΠ, μορφής στρογγυλού αγωγού (μονόκλωνοι και πολύκλωνοι) και ταινίας, δοκιμασμένοι κατά ΕΛΟΤ Ε 62561 - 2

Ø8mm copper solid round conductor, code 6420008-70

Images
Additional Information
Certificates
tested
Technical data
Diameter 8 mm.
Cross sectional area 50 mm2.
Material Copper (Cu).
Electrical resistivity <0,018 μΩm.
Electrical resistance ≤0,387 Ω/km.
Tensile strength 200 – 450 N/mm2.
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected buried in ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected in concrete with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn.
Straightening For straightening can be used straightener, ELEMKO code 6900100.
Copper conductor used as air termination conductor, down conductor and earth conductor.
GTIN:
6420008-80
,
Product code:
6420008-70
,
Customs tariff No.:
929.3.5.2
,
Gross weight:
450.00
gr/m,
PU:
70.00
m
Related products

Ø6mm copper solid round conductor, code 6420006-70

Images
Additional Information
Certificates
Technical data
Diameter 6 mm.
Cross sectional area 28 mm2.
Material Copper (Cu).
Electrical resistivity <0,018 μΩm.
Electrical resistance ≤0,727 Ω/km
Tensile strength 200 – 450 N/mm2.
Installation Above ground, embedded in concrete.
Can be connected above ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected in concrete with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn.
Straightening For straightening can be used straightener, ELEMKO code 6900100.
Copper conductor used as air termination conductor and down conductor, were mechanical strength is not an essential requirement.
GTIN:
6420006-80
,
Product code:
6420006-70
,
Customs tariff No.:
929.3.5.2
,
Gross weight:
250.00
gr/m,
PU:
200.00
m
Related products

40x3mm copper tape conductor, code 6420403-70

Images
Additional Information
Certificates
tested
Technical data
Width 40 mm.
Thickness 3 mm.
Cross sectional area 120 mm2.
Material Copper (Cu).
Electrical resistivity <0,018 μΩm.
Tensile strength 200 – 450 N/mm2.
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected buried in ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected in concrete with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn.
Straightening For straightening can be used straightener, ELEMKO code 6900100.
Copper tape used as air termination conductor, down conductor and earth conductor.
GTIN:
6420403-80
,
Product code:
6420403-70
,
Customs tariff No.:
929.3.5.2
,
Gross weight:
1068.00
gr/m,
PU:
35.00
m
Related products

30x3mm copper tape conductor, code 6420330-70

Images
Additional Information
Certificates
tested
Technical data
Width 30 mm.
Thickness 3 mm.
Cross sectional area 90 mm2.
Material Copper (Cu).
Electrical resistivity <0,018 μΩm.
Tensile strength 200 – 450 N/mm2.
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected buried in ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected in concrete with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn.
Straightening For straightening can be used straightener, ELEMKO code 6900100.
Copper tape used as air termination conductor, down conductor and earth conductor.
GTIN:
6420330-80
,
Product code:
6420330-70
,
Customs tariff No.:
929.3.5.2
,
Gross weight:
801.00
gr/m,
PU:
40.00
m
Related products

30x2mm copper tape conductor, code 6420030-70

Images
Additional Information
Certificates
tested
Technical data
Width 30 mm.
Thickness 2 mm.
Cross sectional area 60 mm2.
Material Copper (Cu).
Electrical resistivity <0,018 μΩm.
Tensile strength 200 – 450 N/mm2.
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected buried in ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected in concrete with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn.
Straightening For straightening can be used straightener, ELEMKO code 6900100.
Copper tape used as air termination conductor, down conductor and earth conductor.
GTIN:
6420030-80
,
Product code:
6420030-70
,
Customs tariff No.:
929.3.5.2
,
Gross weight:
534.00
gr/m,
PU:
30.00
m
Related products

25x3mm copper tape conductor, code 6420253-70

Images
Additional Information
Certificates
tested
Technical data
Width 25 mm.
Thickness 3 mm.
Cross sectional area 75 mm2.
Material Copper (Cu).
Electrical resistivity <0,018 μΩm.
Tensile strength 200 – 450 N/mm2.
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected buried in ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected in concrete with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn.
Straightening For straightening can be used straightener, ELEMKO code 6900100.
Copper tape used as air termination conductor, down conductor and earth conductor.
GTIN:
6420253-80
,
Product code:
6420253-70
,
Customs tariff No.:
929.3.5.2
,
Gross weight:
667.00
gr/m,
PU:
40.00
m
Related products

25x2mm copper tape conductor, code 6420252-70

Images
Additional Information
Technical data
Width 25 mm.
Thickness 2 mm.
Cross sectional area 50 mm2.
Material Copper (Cu).
Electrical resistivity <0,018 μΩm.
Tensile strength 200 – 450 N/mm2.
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected buried in ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected in concrete with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn.
Straightening For straightening can be used straightener, ELEMKO code 6900100.
Copper tape used as air termination conductor, down conductor and earth conductor.
GTIN:
6420252-80
,
Product code:
6420252-70
,
Customs tariff No.:,
Gross weight:
450.00
gr/m,
PU:
40.00
m
Related products

95mm2 nominal cross sectional area copper stranded conductor, code 6420195-70

Images
Additional Information
Certificates
tested
Technical data
Diameter 12,60 mm.
Cross sectional area 95 mm2.
Material Copper (Cu).
Electrical resistivity <0,018 μΩm.
Electrical resistance ≤0,195 Ω/km.
Tensile strength 200 – 450 N/mm2.
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected buried in ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected in concrete with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn.
Copper stranded conductor used as air termination conductor, down conductor and earth conductor.
GTIN:
6420195-80
,
Product code:
6420195-70
,
Customs tariff No.:,
Gross weight:
833.00
gr/m,
PU:
70.00
m
Related products

70mm2 nominal cross sectional area copper stranded conductor, code 6420170-70

Images
Additional Information
Certificates
tested
Technical data
Diameter 10,7 mm.
Cross sectional area 70 mm2.
Material Copper (Cu).
Electrical resistivity <0,018 μΩm.
Electrical resistance ≤0,270 Ω/km.
Tensile strength 200 – 450 N/mm2.
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected buried in ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected in concrete with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn.
Copper stranded conductor used as air termination conductor, down conductor and earth conductor.
GTIN:
6420170-80
,
Product code:
6420170-70
,
Customs tariff No.:
929.3.5.2
,
Gross weight:
601.00
gr/m,
PU:
100.00
m
Related products

50mm2 nominal cross sectional area copper stranded conductor, code 6420108-70

Images
Additional Information
Certificates
tested
Technical data
Diameter 8,9 mm.
Cross sectional area 50 mm2.
Material Copper (Cu).
Electrical resistivity <0,018 μΩm.
Electrical resistance ≤0,391 Ω/km.
Tensile strength 200 – 450 N/mm2.
Installation Above ground, buried in ground, embedded in concrete.
Can be connected above ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected buried in ground with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu.
Can be connected in concrete with Cu, Cu-A (copper alloy), Cu/eSn, Stainless Steel (SSt), St/eCu, St/tZn.
Copper stranded conductor used as air termination conductor, down conductor and earth conductor.
GTIN:
6420108-80
,
Product code:
6420108-70
,
Customs tariff No.:
929.3.5.2
,
Gross weight:
415.00
gr/m,
PU:
100.00
m
